Insurance Telematics cloud service for insurance company administration vehicles based on OBD terminal

FOB Reference Price:Get Latest Price
$200,000.00 - $350,000.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Model Number:
Fleet management solution
Product Name:
Fleet management solution
Fleet management
Cloud service system
for fleet manager and driver
Service value:
Safe, save and efficient
Software+hardware+cloud service
Supply Ability
Supply Ability:
30000 Unit/Units per Year for cloud service
Packaging & Delivery
Packaging Details
Standard carton packing
Fleet Management

ChainwayTSP fleet management solution is to address the dynamic challenges of fleets risk management, with big data analysis cloud service system and OBD terminal. And helping fleets improve the level of risk management and operational efficiency.

We sincerely invite you to become our partner and develop the global market to achieve win-win business.

ChainwayTSP cloud service based on risk management that owns the closed-loop fleet management system, devotes to lowering the risk of fleet management and accident rate, as well as improving the road traffic safety. More safety and more efficiency.

ChainwayTSP fleet management services for a wide variety of fleets. For example, heavy truck fleets, light truck fleets, government and enterprise fleets, logistics vehicles, rental vehicles and survey vehicles.

Cloud Service System

Use the cloud service system in combination with big data analysis to obtain users’ operation data


Terminal spec
General Specifications
SensorAccelerator sensor and shock sensor
Operation VoltageDC 9~36V
Active current70mA @ 12V
Operation Temperature-30℃~75℃
Operating Humidity5% to 95%, non-condensing
GPS Specifications
ModuleU- Blox NEO-6M
Position Accuracy≤ 2.5m
Speed Accuracy≤0.1m/s
SensitivityTracking: -162dBm
Acquisition TimeCold Start: 29s/Warm Start: 29s/Hot Start: 1s
GSM Specifications
Frequency Quad-band: 850/900/1800/1900MHz

GPRS multi-slot class 10

GPRS mobile station class B

Receiving Sensitivity<-107dBm
Mini USB Port1
GPS AntennaInternal
GSM AntennaInternal
OBDII Connector Standard OBD II
Air Interface Protocol
Transmit ProtocolTCP, UDP
OBD Protocols Access

ISO 15765-4 (CAN)

ISO 14230-4 (Keyword Protocol 2000)

ISO 9141-2 (Asian, European, Chrysler vehicles)

SAE J1850 VPW (GM vehicles)

SAE J1850 PWM (Ford vehicles)

ISO 11898 (raw CAN)

SAE J1939 OBD protocol

Cases Study

 Coca-Cola Fleet risk Management Project



The Coca-Cola fleet mainly distributes urban beverages. Due to lack of scientific management, complex road conditions and poor traffic environment in Chongqing, the traffic accidents and operation costs of the fleets have been constantly increasing. Since February 2016, Chainwaytsp provided fleet management services for Coca-Cola.


Requirements: Reduce fuel consumption, reduce accident rate


Service and measures:

Distinguish driving safety degree

Fine fuel consumption management

Accident scientific analysis



By sending weekly reports to the fleet, according to the driving score of fleets and analyzing the accidents, the average driving score of the fleets have steadily increased. The total number of accidents was 19 in 2015 , and the number of accidents was 6 in 2016The number of accidents dropped by 68.4%. The amount of accidents in 2015 was 97151.99 , and in 2016 it was 4707.93, and the amount of accidents was reduced by 95.1%.

Company Information

Founded in 2006 and headquartered in Shenzhen, ChainwayTSP Co., Ltd is an International high-tech enterprise that specializes in providing telematics intelligent transportation ecological technology service. Today ChainwayTsp national branches located in Beijing, Shanghai, Chongqing, Xi’an, Wuhan, Ningbo and have Co-partners in different countries .


Products and services are widely used in automobile insurance, logistics fleets, government and enterprise fleets, intelligent travel, auto rental industries, reaching more than 170 countries and regions around the world. Up to now, our fleet management cloud service system has served 270,000 vehicles and more than 4,500 operational fleets, including those from global Top 500 enterprises such as Huawei, Coca-Cola, Oway etc.

Company awards
